Leistungsmodule
Ausstattung:
• Hohe Stoßstromfähigkeit
• Geringer Ableitstrom
• RoHS-konform
• Elektrisch isolierter Sockel
• Industriestandard-Pakete
Anwendungen:
• Elektronische Schweißsteuerungen
• Anwendungen zum Laden von Batterien
• Steuerung der Beleuchtung
• AC- und DC-Motorantriebe und Steuerungen
• HVAC-Steuerungssysteme
Paket: M51
Paket: M16
Paket: M10
| Teil Nummer | Paket | VRRM(V) | IO(A) | IFSM(A) | VF(V) | IR(uA) | Tj(℃) | Datenblatt |
| MDC200GB-X | M69GB | 1200 - 1800 | 200 | 6800 | 1.3 | 18 | -40bis150 |  |
| MDC200GB-12 | M69GB | 1200 | 200 | 6800 | 1.3 | 18 | -40bis150 | |
| MDC200GB-16 | M69GB | 1600 | 200 | 6800 | 1.3 | 18 | -40bis150 | |
| MDC200GB-18 | M69GB | 1800 | 200 | 6800 | 1.3 | 18 | -40bis150 | |
| MDS250G-X | M23G | 1200 - 1800 | 250 | 2800 | 1.45 | 20 | -40bis150 | |
| MDS250G-12 | M23G | 1200 | 250 | 2800 | 1.45 | 20 | -40bis150 | |
| MDS250G-16 | M23G | 1600 | 250 | 2800 | 1.45 | 20 | -40bis150 | |
| MDS250G-18 | M23G | 1800 | 250 | 2800 | 1.45 | 20 | -40bis150 | |
| MDS150J-X | M10J | 1200 - 1800 | 150 | 1800 | 1.40 | 16 | -40bis150 | |
| MDS150J-12 | M10J | 1200 | 150 | 1800 | 1.40 | 16 | -40bis150 | |
| MDS150J-16 | M10J | 1600 | 150 | 1800 | 1.40 | 16 | -40bis150 | |
| MDS150J-18 | M10J | 1800 | 150 | 1800 | 1.40 | 16 | -40bis150 | |
| MDS100G-X | M16G | 1200 - 1800 | 100 | 920 | 1.3 | 10 | -40bis150 | |
| MDS100G-12 | M16G | 1200 | 100 | 920 | 1.3 | 10 | -40bis150 | |
| MDS100G-16 | M16G | 1600 | 100 | 920 | 1.3 | 10 | -40bis150 | |
| MDS100G-18 | M16G | 1800 | 100 | 920 | 1.3 | 10 | -40bis150 | |
| MDC100G-X | M10J | 1200 - 1800 | 100 | 2500 | 1.3 | 10 | -40bis150 | |
| MDC100G-12 | M10J | 1200 | 100 | 2500 | 1.3 | 10 | -40bis150 | |
| MDC100G-16 | M10J | 1600 | 100 | 2500 | 1.3 | 10 | -40bis150 | |
| MDC100G-18 | M10J | 1800 | 100 | 2500 | 1.3 | 10 | -40bis150 | |
| MDS160G-X | M16G | 1200 - 1800 | 160 | 1800 | 1.42 | 16 | -40bis150 | |
| MDS160G-12 | M16G | 1200 | 160 | 1800 | 1.42 | 16 | -40bis150 | |
| MDS160G-16 | M16G | 1600 | 160 | 1800 | 1.42 | 16 | -40bis150 | |
| MDS160G-18 | M16G | 1800 | 160 | 1800 | 1.42 | 16 | -40bis150 | |
| MDST150-X | M51B | 1200 - 1800 | 150 | 1800 | 1.40 | 100 | -40bis150 | |
| MDST150-08 | M51B | 800 | 150 | 1800 | 1.40 | 100 | -40bis150 | |
| MDST150-12 | M51B | 1200 | 150 | 1800 | 1.40 | 100 | -40bis150 | |
| MDST150-16 | M51B | 1600 | 150 | 1800 | 1.40 | 100 | -40bis150 | |
| MDST200-X | M51B | 1200 - 1800 | 200 | 2240 | 1.45 | 100 | -40bis150 | |
| MDST200-08 | M51B | 800 | 200 | 2240 | 1.45 | 100 | -40bis150 | |
| MDST200-12 | M51B | 1200 | 200 | 2240 | 1.45 | 100 | -40bis150 | |
| MDST200-16 | M51B | 1600 | 200 | 2240 | 1.45 | 100 | -40bis150 | |
| CKKX | - | 400 - 2200 | 27 - 1000 | 560 - 32000 | 1.25 - 1.95 | - | -40bis125 | |
| CKKD | - | 400 - 2200 | 55 - 1000 | 1660 - 31000 | 1.25 - 1.57 | - | -40bis125 | |
