Fast Recovery Diodes
Features
– Fast switching for high efficiency
– Low reverse leakage current RoHS
– High current capability COMPLIANT
– Low forward voltage drop
– Low cost
– Meet UL flammability classification 94V-0
Package: D0-41
Package: SMC
Package: R-6
Package: SMB
| Part Number | Package | VRRM(V) | IO(A) | IFSM(A) | VF(V) | IR(uA) | Trr(nS) | Datasheet |
| RS1X | A-SMA | 50 - 1000 | 1.0 | 30 | 1.3 | 5.0 | 150 |  |
| RS1AA | A-SMA | 50 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1BA | A-SMA | 100 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1DA | A-SMA | 200 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1GA | A-SMA | 400 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1JA | A-SMA | 600 | 1.0 | 30 | 1.3 | 5.0 | 250 | |
| RS1KA | A-SMA | 800 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| RS1MA | A-SMA | 1000 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| FR10XG | DO-41 | 50 - 1000 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR101G | DO-41 | 50 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR102G | DO-41 | 100 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR103G | DO-41 | 200 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR104G | DO-41 | 400 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR105G | DO-41 | 600 | 1.0 | 30 | 1.3 | 5.0 | 250 | |
| FR106G | DO-41 | 800 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| FR107G | DO-41 | 1000 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| FR15XG | DO-15 | 50 - 1000 | 1.5 | 50 | 1.3 | 5.0 | 150 | |
| FR151G | DO-15 | 50 | 1.5 | 50 | 1.3 | 5.0 | 150 | |
| FR152G | DO-15 | 100 | 1.5 | 50 | 1.3 | 5.0 | 150 | |
| FR153G | DO-15 | 200 | 1.5 | 50 | 1.3 | 5.0 | 150 | |
| FR154G | DO-15 | 400 | 1.5 | 50 | 1.3 | 5.0 | 150 | |
| FR155G | DO-15 | 600 | 1.5 | 50 | 1.3 | 5.0 | 250 | |
| FR156G | DO-15 | 800 | 1.5 | 50 | 1.3 | 5.0 | 500 | |
| FR157G | DO-15 | 1000 | 1.5 | 50 | 1.3 | 5.0 | 500 | |
| RS1XL | SOD-123FL | 50 - 1000 | 1.0 | 25 | 1.3 | 5.0 | 150 | |
| RS1AL | SOD-123FL | 50 | 1.0 | 25 | 1.3 | 5.0 | 150 | |
| RS1BL | SOD-123FL | 100 | 1.0 | 25 | 1.3 | 5.0 | 150 | |
| RS1DL | SOD-123FL | 200 | 1.0 | 25 | 1.3 | 5.0 | 150 | |
| RS1GL | SOD-123FL | 400 | 1.0 | 25 | 1.3 | 5.0 | 150 | |
| RS1JL | SOD-123FL | 600 | 1.0 | 25 | 1.3 | 5.0 | 250 | |
| RS1KL | SOD-123FL | 800 | 1.0 | 25 | 1.3 | 5.0 | 500 | |
| RS1ML | SOD-123FL | 1000 | 1.0 | 25 | 1.3 | 5.0 | 500 | |
| RS1X | SMA | 50 - 1000 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1A | SMA | 50 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1B | SMA | 100 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1D | SMA | 200 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1G | SMA | 400 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| RS1J | SMA | 600 | 1.0 | 30 | 1.3 | 5.0 | 250 | |
| RS1K | SMA | 800 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| RS1M | SMA | 1000 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| RS2XA | SMA | 50 - 1000 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2AA | SMA | 50 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2BA | SMA | 100 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2DA | SMA | 200 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2GA | SMA | 400 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2JA | SMA | 600 | 2.0 | 60 | 1.3 | 5.0 | 250 | |
| RS2KA | SMA | 800 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| RS2MA | SMA | 1000 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| RS2X | SMB | 50 - 1000 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2A | SMB | 50 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2B | SMB | 100 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2D | SMB | 200 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2G | SMB | 400 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| RS2J | SMB | 600 | 2.0 | 60 | 1.3 | 5.0 | 250 | |
| RS2K | SMB | 800 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| RS2M | SMB | 1000 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| RS3XB | SMB | 50 - 1000 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3AB | SMB | 50 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3BB | SMB | 100 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3DB | SMB | 200 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3GB | SMB | 400 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3JB | SMB | 600 | 3.0 | 100 | 1.3 | 5.0 | 250 | |
| RS3KB | SMB | 800 | 3.0 | 100 | 1.3 | 5.0 | 500 | |
| RS3MB | SMB | 1000 | 3.0 | 100 | 1.3 | 5.0 | 500 | |
| RS3X | SMC | 50 - 1000 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3A | SMC | 50 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3B | SMC | 100 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3D | SMC | 200 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3G | SMC | 400 | 3.0 | 100 | 1.3 | 5.0 | 150 | |
| RS3J | SMC | 600 | 3.0 | 100 | 1.3 | 5.0 | 250 | |
| RS3K | SMC | 800 | 3.0 | 100 | 1.3 | 5.0 | 500 | |
| RS3M | SMC | 1000 | 3.0 | 100 | 1.3 | 5.0 | 500 | |
| FR10XSG | A-405 | 50 - 1000 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR101SG | A-405 | 50 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR102SG | A-405 | 100 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR103SG | A-405 | 200 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR104SG | A-405 | 400 | 1.0 | 30 | 1.3 | 5.0 | 150 | |
| FR105SG | A-405 | 600 | 1.0 | 30 | 1.3 | 5.0 | 250 | |
| FR106SG | A-405 | 800 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| FR107SG | A-405 | 1000 | 1.0 | 30 | 1.3 | 5.0 | 500 | |
| 1N493XG | DO-41 | 50 - 600 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| 1N4933G | DO-41 | 50 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| 1N4934G | DO-41 | 100 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| 1N4935G | DO-41 | 200 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| 1N4936G | DO-41 | 400 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| 1N4937G | DO-41 | 600 | 1.0 | 30 | 1.3 | 5.0 | 200 | |
| FR20XG | DO-15 | 50 - 1000 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| FR201G | DO-15 | 50 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| FR202G | DO-15 | 100 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| FR203G | DO-15 | 200 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| FR204G | DO-15 | 400 | 2.0 | 60 | 1.3 | 5.0 | 150 | |
| FR205G | DO-15 | 600 | 2.0 | 60 | 1.3 | 5.0 | 250 | |
| FR206G | DO-15 | 800 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| FR207G | DO-15 | 1000 | 2.0 | 60 | 1.3 | 5.0 | 500 | |
| FR30XG | DO-27 | 50 - 1000 | 3.0 | 125 | 1.3 | 5.0 | 150 | |
| FR301G | DO-27 | 50 | 3.0 | 125 | 1.3 | 5.0 | 150 | |
| FR302G | DO-27 | 100 | 3.0 | 125 | 1.3 | 5.0 | 150 | |
| FR303G | DO-27 | 200 | 3.0 | 125 | 1.3 | 5.0 | 150 | |
| FR304G | DO-27 | 400 | 3.0 | 125 | 1.3 | 5.0 | 150 | |
| FR305G | DO-27 | 600 | 3.0 | 125 | 1.3 | 5.0 | 250 | |
| FR306G | DO-27 | 800 | 3.0 | 125 | 1.3 | 5.0 | 500 | |
| FR307G | DO-27 | 1000 | 3.0 | 125 | 1.3 | 5.0 | 500 | |
| 1FXG | R-1 | 50 - 1000 | 1.0 | 30.0 | 1.3 | 5.0 | 150 | |
| 1F1G | R-1 | 50 | 1.0 | 30.0 | 1.3 | 5.0 | 150 | |
| 1F2G | R-1 | 100 | 1.0 | 30.0 | 1.3 | 5.0 | 150 | |
| 1F3G | R-1 | 200 | 1.0 | 30.0 | 1.3 | 5.0 | 150 | |
| 1F4G | R-1 | 400 | 1.0 | 30.0 | 1.3 | 5.0 | 150 | |
| 1F5G | R-1 | 600 | 1.0 | 30.0 | 1.3 | 5.0 | 250 | |
| 1F6G | R-1 | 800 | 1.0 | 30.0 | 1.3 | 5.0 | 500 | |
| 1F7G | R-1 | 1000 | 1.0 | 30.0 | 1.3 | 5.0 | 500 | |
| FR60XG | R-6 | 50 - 1000 | 6.0 | 220 | 1.3 | 5.0 | 150 | |
| FR601G | R-6 | 50 | 6.0 | 220 | 1.3 | 5.0 | 150 | |
| FR602G | R-6 | 100 | 6.0 | 220 | 1.3 | 5.0 | 150 | |
| FR603G | R-6 | 200 | 6.0 | 220 | 1.3 | 5.0 | 150 | |
| FR604G | R-6 | 400 | 6.0 | 220 | 1.3 | 5.0 | 150 | |
| FR605G | R-6 | 600 | 6.0 | 220 | 1.3 | 5.0 | 250 | |
| FR606G | R-6 | 800 | 6.0 | 220 | 1.3 | 5.0 | 500 | |
| FR607G | R-6 | 1000 | 6.0 | 220 | 1.3 | 5.0 | 500 | |
