Magnetron Modulators
Our systems require about one third of the space of alternative solutions yet still offer around 30% higher efficiency, two operating advantages that especially appeal to cancer treatment providers. Their high reliability and performance also attract many end-users. We provide everything from a pure high-voltage pulse modulator to a turn-key RF unit including magnetron, control system and related components.
RF peak power: 0.2 – 2 MW
Pulse voltage: 20 – 40 kV
Pulse current: 20 – 100 A
Modulator peak: 20 – 100
Modulator avg.: 1 kW
RF peak power: 1 – 3.1 MW
Pulse voltage: 30 – 52 kV
Pulse current: 30 – 120 A
Modulator peak: 6.2 MW
Modulator avg.: 8 kW
RF peak power: 1 – 3.1 MW
Pulse voltage: 30 – 52 kV
Pulse current: 30 – 120 A
Modulator peak: 6.2 MW
Modulator avg.: 8 kW
RF peak power: 2.5 – 5 MW
Pulse voltage: 40 – 75 kV
Pulse current: 30 – 250 A
Modulator peak: 14 MW
Modulator avg.: 16 kW
